Specifications:

  • Maximum Power Output: 350 watts/ch (4 ohms)
  • Continuous Power Output: 200 watts/ch (8 ohms)
  • Total Harmonic Distortion: < 0.0075%
  • Intermodulation Distortion (60 Hz : 7kHz, 4:1): < 0.03%
  • Frequency Response
    • Phono Input 20 Hz - 20k Hz, 0 ± 0.5 dB
    • Line Level Inputs 10 Hz - 100k Hz, 0 ± 0.5 dB
  • Damping Factor 600 (20 Hz - 20 kHz, 8 ohms)
  • Input Sensitivity / Impedance
    • Phono Input (MM) 5.2 mV / 47k ohms
    • Line Level Inputs (RCA) 340 mV / 5.6k ohms
    • Line Level Inputs (XLR) 540 mV / 100k ohms
  • Signal to Noise Ratio (IHF A-weighted)
    • Phono Input (MM) 80 dB
    • Line Level Inputs 103 dB
  • Digital to Analog Converters: Texas Instruments

Digital Section

  • Frequency Response: 10 Hz - 90k Hz (0 ± 2 dB, Max)
  • Signal to Noise Ratio (IHF A-weighted): 102 dB
  • Input Sensitivity/Impedance: 0 dBfs / 75 ohms
  • Preamplifier Output Level: 1.43 V (at -20 dB)
  • Coaxial/Optical Digital Signals: SPDIF LPCM (up to 24-bit / 192k Hz)
  • PC-USB:
    • USB Audio Class 2.0 (up to 32-bit / 384k Hz) (Driver installation required)
    • Support MQA and MQA Studio (up to 24-bit / 384k Hz )
    • Roon Tested
Coaxial 3
Optical 3
PC-USB 1

(775)

SKU 775
Brand Rotel
Shipping Weight 20.0000kg
Shipping Width 0.260m
Shipping Height 0.510m
Shipping Length 0.550m
Shipping Cubic 0.072930000m3
